TH2018KC

Product overview

TH2018KC  is a real-time thermocouple thermometer, making full use of the hardware resources of mobile phone and computer, which used with mobile phone or computer. With exquisite appearance and Standard K type thermocouple probe ,the temperature range of this product is 0~1024ºC. In addition,the product is equipped with a temperature-measuring chip, temperature range is -40ºC~125ºC, which can monitor the internal temperature when the product is running.


TH2018K series comparison

If the device under test is powered, please use our isolated thermocouple meter for preventing damage to the phone or computer

If the temperature range to be measured is wide, please use our wide range type thermocouple meter
If your probe is plug type, please chose our plug-in thermocouple meter.

Non-isolated thermocouple meter
 USB Type AAndroidRelayPortTemperature Range
TH2018KA√××USB Industrial Thermocouple Thermometer K-Type Probe Apply to Boiler High Temperature Environmental Detection0~1024ºC
TH2018KB√√×0~1024ºC
TH2018KC√√√0~1024ºC
TH2018KF√√√-200~700ºC
TH2018KH√√√USB Industrial Thermocouple Thermometer K-Type Probe Apply to Boiler High Temperature Environmental Detection0~+1024ºC
Isolated thermocouple meter
 USB Type AAndroidRelayPortTemperature Range
TH2018KD√√√USB Industrial Thermocouple Thermometer K-Type Probe Apply to Boiler High Temperature Environmental Detection0~1024ºC
TH2018KK√√√USB Industrial Thermocouple Thermometer K-Type Probe Apply to Boiler High Temperature Environmental Detection0~1024ºC
TH2018KG√√√-200~700ºC

a)USB Port: Using USB port, the device communicates with the host computer.
b)Thermocouple Isolation: thermocouple probe circuit and internal circuit isolation, to avoid damage the computer when measure temperature of high voltage equipment.
c)Android : Supports Android APP for monitoring (only single-mode operation is supported, and Micro USB Port is used as power in mobile mode)
d)Relay: It can be connected to external boilers, motors and other equipment to control the on/off of the equipment by judging the temperature.
e)Buzzer: When the temperature exceeds the threshold range, the buzzer will beep.
f)Outer measurement range:K-type thermocouple probe temperature measurement range



Software introduction
Real-time Temperature Measurement

View real-time temperature data via a computer connected device

Email alarm
Set the alarm threshold, set the send mode to be “Send mail when alarming”, then, through the mailbox SMTP service, the software will send an alarm email to the aim mailbox when the measured temperature exceeds the alarm temperature.

Remote data
Users can view data on a computer without a connected device by registering an account.

Data to file
The software automatically stores the measurement data as a file. The user can set the file type and storage path.
Software Download link:http://pcsensor.en.made-in-china.com

Product features

a)Support COM port mode, free to provide secondary development instruction text and instructions
b)The device uses a metal shell, which can well shield external interference, batch order can be printed LOGO
c)The device has two external terminals, fixed by welding rather than screw, to ensure long-term use to avoid loosening.
